冬季特效图#5第1张图片

Winter Special #5

由专筑网严越,刘庆新编译

自从去年的失误,今年我挑选新东西来做冬季特效图的研究实验室设计。这次将照相机移动到体系结构下方,以便提供在靠近入口时体验的感觉。图像是直接用许多周边环境纹理和风景快速地创造。你会看到的屏幕和半透明的面板是在 photoshop 中添加的。我仍然在试验这一部分的设计,但通过这个图像,我能够专注于细节。下面是一个快速的指导,然后有所有以前的冬季特效图的链接。

Since I dropped the ball last year, I am picking things back up this year with a new winter special illustration of the research lab design. This view moves the camera underneath the architecture to give a sense of the experience one has when approaching the entrance. The image was pretty straight forward to create with much of the context texture and landscape coming together quickly. You will see that the screens and translucent panels were all added in Photoshop. I am still experimenting with this part of the design but was able to narrow in on final detailing through this image. Below is a super quick breakdown followed by links to all previous winter special posts.



1. Sketchup建模

冬季特效图#5第2张图片

上面,一个 Sketchup 模型的截图

1. Sketchup Model
Above, a screenshot of the Sketchup model


2. V-Ray 基础渲染

冬季特效图#5第3张图片

对于 Vray渲染,我关闭了外部的墙壁屏幕,以便我可以使用材料选择内部信息以备以后的使用。

2. V-Ray Base Rendering
For the V-Ray rendering, I turned off the wall screens on the exterior so that I could use the material ID to select the interior information for later use.


3. 背景和灯光调节

冬季特效图#5第4张图片

我调整了图像的色调平衡,以增加对比度,使结构的下方变暗。然后我添加了一些地面纹理和背景树。地面是由3个不同的积雪的纹理与阴影的混和运用。

3. Context and Light Adjustments
I adjusted the levels of the image to increase the contrast and darken the underside of the architecture. I then added in some ground textures and background trees. The ground is made up of 3 different snowy textures with a shadow draped over everything.


4. 屏幕和室内灯光

冬季特效图#5第5张图片

在 photoshop 中,我外观上添加了屏幕和在核心的大楼用半透明材料。我在考虑稍后创建一个快速教程。

4. Screens and Interior Light
In Photoshop, I added screens on the exterior and the suggestion of a translucent material in the core of the building. I am considering creating a quick tutorial on this later.


5. 树木和周围环境

冬季特效图#5第6张图片

树木和周围环境增加了规模,故事性和深度。

5. Trees and Entourage
Trees and entourage were added for scale, narrative, and depth.


6. Topaz滤镜颜色调整

冬季特效图#5第7张图片

最后,我把颜色调整到一个更温暖的范围。所有我过去的冬季特效图呈现的都是凉爽的一面,所以我决定走一条不同的风格路线。

6. Topaz Color Adjustments
Finally, I tweaked the colors towards a much warmer range. All my past winter specials were all on the cool side, so I decided to go a different route this year.


Winter Special # 1 (2011)

冬季特效图#5第8张图片


Winter Special # 2 (2012)

冬季特效图#5第9张图片


Winter Special # 3 (2013)

冬季特效图#5第10张图片


Winter Special # 4 (2014)

冬季特效图#5第11张图片


Winter Special #5 (2016)

冬季特效图#5第12张图片


出处:本文译自visualizingarchitecture.com/,转载请注明出处。
